Hi Power Output <0.75kW> can offer Wide Speed Range & Heavy Duty
Wide Speed Range
Heavy Duty
Low to Floor Implementation type
Gear motor can be mounted directly to the wheels allowing the AGV to be low to Floor type
Slim &Light Weight
Overall length has been reduced by 80mm and weight reduced by 40% making effective use of AGV:s Space ( Compared with our AFC Type
Waterproof & 2G Compatible
Standard line up with IP65 Protection class as well as with vibration resistance compatible to 2G which can be used for Outdoor AGV specifications
Wide Speed Range
Fine Tune Run Speed for Application that require Precision and control
Capacity
Rated Output Speed
Speed Control Range
0.75kW
3000r/min
80～4000r/min
Position Control
Accurate Position Setting available with 30 detection point/round
Motor Power & Reduction Ratio
Power
Parallel shaft (APG)
Perpendicular shaft(F3)
0.75kW
1/15～1/60
1/10～1/60
Driver Function
Provide Various Speed Control Mode
Easy to Set Control Modefor Several Motors all at once by using Dedicated Software
Provide Five (5) Speed Control Mode
Electromagnetic Brake Function
Electromagnetic Brake Function Available. (Brake Function will be released when No-Power) Easy to use this Function, Machine can be moved by Manual when Low Battery.
